Silicone Coated Pet Release Liner /Pet Release Base Film

Availability:

Quantity:



Inquire Add to Basket

Transport Package:
Standard Packing
Specification:
as per customer demand
Trademark:
REYDA
Origin:
China

Product Description

Our company can provide on line silicone coated PET release liner , or release base film

Base film for release liner and optical protective film

Application: used for release film,protective film,and graphic printing film
Characters: High cleanliness,lower surface roughness, excellent flatness. Dimensional thermal stablity, great appearance
Standard thickness: 23 micron, 25mic, 50 micron, 75 micron

Property		Unit			TEST VALUE				TEST
Property		Unit			TEST VALUE				METHOD
									METHOD

Thickness		μm	23	50		75	125	175	ASTM D374

Tensile strength ≥	MD	MPa	240	220		200	180	175

	TD		265	255		225	205	170	ASTM D882
	TD		265	255		225	205	170

Elongation at break ≥	MD	%	120	125		130	145	190
	MD		120	125		130	145	190

	TD		105	110		115	125	165
	TD		105	110		115	125	165

Heat	MD		1.4	1.25		1.25	1.25	1.2
shrinkage(150ºC,15min)		%							ASTM D1204
shrinkage(150ºC,15min)	TD	%	0	0.1		0.1	0.2	0.2	ASTM D1204
≤	TD		0	0.1		0.1	0.2	0.2

WETTING TENSION		Dyne/cm	56	56		56	56	56	ASTM D 2578

TRANSMITTANCE		%	89.5	89.5		89.5	89.3	89
									ASTM D1003
CLARITY		%	99.2	99		99	98.8	98.6	ASTM D1003

HAZE ≤		%	1.5	1.6		1.7	1.8	2

APPEARANCE		N/M	OK	OK		OK	OK	OK	N/M

All details in this data sheet are based on our present technical knowledge, They neither guarantee characteristics of products nor their suitability for a particular application.
