Co-extruded Oriented Pearlised Film
| Quantity: | |
|---|---|
Opaque
Soft
BOPP
Food
Basic Level
Bag
Co-extruded Oriented Pearlised Film (PD)
Description
PD is one side treated the other side heat sealable BOPP film. It’s designed for lamination with reverse printed PP for package of ice-cream, confectionary, soap, wash powder.
Features
High stiffness, low static property, suitable for high speed laminating processing
Good machineability with excellent lap heat seal, printing and laminating properties
Outstanding pearl luster provides attractive eye appealing
Typical Properties
Properties | Test Method | Unit | Value | ||||||
GENERAL |
| Thickness Density Unit weight Yielding | ASTM D792 ASTM D792 ASTM D792 ASTM D792
| μm 25 g/cm3 0.67 g/m² 16.75 m²/kg 59.70
| 30 0.67 20.10 49.75 |
| 35 0.67 23.45 42.64 | ||
MECHANICAL |
| Tensile Strength
Elongation at Break | MD ASTM D882 TD MD ASTM D882 TD
| 76 130 115 35
| 79 135 120 36 |
| 80 135 125 37 | ||
SURFACE | C.O.F. Surface Tension | Kinetic | ASTM D1894 ASTM D2578 | 0.30 mN/m 38 | 0.30 38 | 0.30 38 | |||
OPTICAL | Whiteness Light Transmission | ASTM E313 ASTM D1003 | % 88 % 48 | 88 43 | 88 40 | ||||
THERMAL | Heat sealing range Heat sealing strength Heat Shrinkage | 1 Sec., 0.18MPa GB/T 12026 MD 120C，2min TD | C N/15mm % | 110- 150 2.0 3.0 1.5 | 110- 150 2.0 3.0 1.5 | 110- 150 2.0 3.0 1.5 | |||
